Blister Packaging Machine Solutions
Loading industry details...
Interactive Machine Finder
Capsule Filling
Pouch Packing
Liquid Capsule Filling Sealing
Blister Packing
Capsule Counting
Effervescent Tablets Tube Filling
Tube Filling and Sealing
Cartoning Machine
Tablet Press Machine
Case Packing Machine
DPP blister Packing machine for sale
DPP-88 Flat-plate Automatic Blister packing Machine
DPP-140 table top blister packaging machine
DPP-260 High-speed Tropical Aluminum Blister Packing Machine
DPP-350 Liquid Blister Packing Machine
DPP-420 Roller Type Blister Packaging Machine
UR-520 4-Side Sealing Blister Packing Equipment
DEBLISTER Blister Pack Emptying Machine
| Model | UR-DPP-88 | UR-DPP-140 | UR-DPP-260 | UR-DPP-350 |
|---|---|---|---|---|
| Blanking frequency (standard) | 15-45 Cutting/min | 15-45 Cutting/min | 15-45 Cutting/min | 15-45 Cutting/min |
| Max. forming area & depth | 120×110×15mm | 158×110×26mm | 250×130×26mm | 350×130×15mm |
| Packaging material PVC | 0.15–0.5×80mm | 0.15–0.5×140mm | 0.25–0.5×250mm | 0.25–0.5×350mm |
| Packaging material PTP | 0.02×80mm | 0.02×140mm | 0.02–0.035×250mm | 0.02–0.035×350mm |
| Packaging material Paper | 50–100g×80mm | 50–100g×140mm | 50–100g×250mm | 50–100g×350mm |
| Power | 380V 50HZ 3.2KW | 380V 50HZ 5.2KW | 380V 50HZ 6.5KW | 380V 50HZ 7KW |
| Air compressor | 0.6–0.8MPA | 0.6–0.8MPA | 0.6–0.8MPA | 0.6–0.8MPA |
| Mould cooling | water/circulating | water/circulating | water/circulating | water/circulating |
| Dimension (LxWxH) | 1600×600×1100mm | 2400×650×1460mm | 2900×750×1600mm | 3550×900×1900mm |
| Weight | 800kg | 1200kg | 2000kg | 2500kg |
Download Urmachine Catalog
Applications of Blister Packaging Machines
Pharmaceutical & Medical Devices
Our solutions adhere to strict GMP and FDA standards, ensuring high-precision blister forming for moisture-sensitive medications. We support ALU-PVC, ALU-ALU (Cold Forming), and sterile medical device packaging.
- Oral Solid Dosages
- Syringes & Ampoules
- Diagnostic Test Strips
- Sterile Instruments
Food & Confectionery Packaging
High-speed, food-grade automated systems designed for portion control and shelf-life extension. Ideal for liquid pastes, chocolates, and unique novelty packaging like chocolate eggs.
- Chocolates & Candies
- Jams & Sauces
- Portion Control Packs
- Dairy & Yogurts
Cosmetics & Beauty Samples
Premium unit-dose packaging that enhances brand value. Perfect for single-use facial masks, skincare testers, and innovative beauty applicators.
- Facial & Eye Masks
- Skincare Sample Units
- Mouthwash Packets
- Essential Oil Vials
Daily Consumer Goods
Durable and retail-ready packaging solutions for hardware and personal care products. Designed for high visibility and anti-theft security in retail environments.
- Toothbrushes & Razors
- Electronic Components
- Stationery & Cards
- Hardware & Tools
Industrial Components
Customized blister solutions for precision engineering parts, electronic sensors, and industrial sub-assemblies requiring physical protection and organization.
- Precision Bearings
- Sensor Modules
- PCB Assemblies
- Automotive Parts
Blister Packaging Classification by Material
ALU-PVC Packaging
Cost-Effective Barrier. The most versatile format for everyday tablets, candy, and small consumer items, offering clear visibility and high production speed.
Inquiry NowALU-ALU Cold Forming
Ultimate Drug Protection.The ultimate barrier solution for moisture-sensitive products, including premium supplements and high-value industrial components.
Inquiry NowALU-PVC-ALU
Humidity Specialist. Designed for extreme environments, ensuring product stability for export goods in high-humidity regions.
Inquiry NowPLASTIC-PAPER
Medical Grade Quality. A professional choice for medical devices and eco-friendly retail packaging, compatible with sustainable mono-materials.
Inquiry NowSuperior Technical Advantages
Our blister packaging machines feature advanced Siemens PLC control systems integrated with high-performance servo drives. This ensures precise synchronization, eliminating mechanical backlash and guaranteeing stable, high-speed operation for pharmaceutical-grade production.
Engineered for excellence, our machines offer superior thermoforming and cold-forming capabilities. The servo-driven traction system allows for micro-adjustments via the HMI interface, ensuring consistent blister pocket integrity and perfect seal quality every cycle.
Designed for multi-product flexibility, our quick-change tooling system utilizes centralized spline shafts. This allows operators to perform tool-free mold changeovers and station adjustments in minutes, significantly reducing downtime and increasing your OEE.
Comply with stringent GMP standards effortlessly. Our optional AI-powered vision system automatically detects missing products, empty pockets, or damaged blisters, triggering an automated rejection process to ensure 100% packaging compliance.
Request a Free Blister Packaging Trial
Send Samples
Ship your tablets, capsules, or products to our facility for professional evaluation.
Sample Trial Run
Our engineers perform a precision blister forming and sealing test using your specific materials.
Full Video Report
Receive a comprehensive HD video report demonstrating the packaging speed and quality of the final result.
Essential Utility Systems for Blister Packing Machines
Optimal performance of your blister packing solution depends on integrated auxiliary systems. Proper chilled water circulation and high-quality compressed air supply are critical for meeting pharmaceutical GMP packaging standards and ensuring machine longevity.
Industrial Water Chiller
Precision Mold Cooling System
High-speed thermoforming processes generate significant heat. An industrial closed-loop water chiller is mandatory to maintain stable temperatures (+15°C to +20°C) for cooling plates. This prevents PVC/Alu film deformation and protects thermally sensitive pharmaceutical products from thermal degradation during the sealing phase.
Dry Air Compressor & Tank
Pneumatic Drive Power
Our blister packing machines utilize robust pneumatic systems for positive blow forming and mechanical punch indexing. To ensure consistent seal quality and prevent moisture contamination, the air supply must be dry, filtered, and regulated at a constant pressure of 0.6 - 0.8 MPa, with a minimum flow rate of 0.35m³/min.
No Stock Photos. Real Factory Track Record.
We believe trust is built on real, transparent transactions. Custom molds and machinery designed exactly to unique pharma, medical, and food specifications ship weekly from our 10,000m² manufacturing base. Here is our live delivery docket:
DPP-140 Pilot Machine + 3 Custom Molds
Destination: Warsaw, Poland (Generics Plant)
DPP-88 Lab Scale Blister Sealer
Destination: California, USA (Biotech Startup Lab)
DPP-260 Rotary Sealing High-Speed Line
Destination: Mumbai, India (Major CMO Client)
Why Sourcing Managers & Engineers Partner with US:
100% FAT (Factory Acceptance Test) Video Validation
We run your raw product samples (pills, syringes, or honey) through consistent pressure testing and shoot high-definition runtime logs before packaging.
In-House CAD Tooling Optimization
Our engineers analyze your foil limits to design soft-transition radiuses, preventing stress breakage during rapid formation.
Multi-Language Operational Support
We provide bilingual English/Chinese system logs, clear wiring schematics, and remote PLC debugging assists to minimize plant downtime.
How the Blister Filling Sealing Machine Works
Unwinding
Active release of PVC/ALU film with high-sensitivity tension balancing.
Pre-heating
PID intelligent temperature control for uniform material softening.
Blister Forming
Positive air pressure creates high-definition pockets (Max 26mm).
Product Feeding
Synchronized planetary feeding ensures 100% filling rate accuracy.
Heat Sealing
Rolling or flat-plate sealing for pharmaceutical-grade hermetic fuses.
Batch Coding
High-clarity mechanical embossing for expiry and batch data.
Indentation
Precisely engineered tear-lines for single-dose patient use.
Servo Traction
Servo-motor indexing ensures millimetric accuracy with zero waste.
Die Cutting
Alloy steel punching system for clean, burr-free pack edges.
Discharge
Automated output delivery ready for downstream cartoning.
Waste Reeling
Automatic scrap winding for a clean, GMP-compliant workspace.
Why Partner with Us as Your Blister Packing Machine Manufacturer?
As a premier manufacturer of blister packaging solutions, we specialize in high-speed, precision-engineered machines tailored for the pharmaceutical, nutraceutical, and medical device industries.
Our expertise spans from individual blister packaging units to fully integrated cartoning and end-of-line systems, ensuring your production line achieves maximum OEE from day one.
Bridging the gap between GMP compliance and industrial-scale production efficiency.
GMP-Compliant Precision Engineering
We adhere strictly to international pharmaceutical standards, utilizing high-grade 316L stainless steel and food-safe contact materials to ensure complete hygiene, traceability, and operational safety.
Turnkey Blister Packaging Customization
From complex thermoforming and cold-forming configurations to automated feeding systems for tablets, capsules, and ampoules, we tailor every module to your specific product geometry.
Global Technical Support & Lifecycle Care
We provide a comprehensive service experience, including FAT/SAT support, detailed documentation for validation, and on-site global technical assistance to keep your packaging line at peak efficiency.
Full quality guarantee on all mechanical and electrical parts for your peace of mind.
Rigorous material-specific testing ensures "plug-and-play" performance upon arrival.
Experienced technicians available for remote commissioning or global on-site dispatch.
Comprehensive in-stock inventory maintained to ensure minimal production downtime.
Flowchart of Components for Blister Sealing Machine
Our blister packaging solution embodies the sophisticated logic of industrial automation. Through the seamless collaboration of the following nine core processes, we ensure that every blister pack meets stringent production standards:
Sheet feeding
Heat forming
Heat sealing and creasing
Servo traction control
Punching and unloading device
Unloading conveyor
Touchscreen control system
Cursor registration system
Waste collection device
Custom feeders to meet your needs
Based on your production needs, we offer four types of aluminum-plastic composite packaging, aluminum-aluminum packaging, paper-plastic packaging, and aluminum-plastic-aluminum packaging. Our R&D team will provide you with the most suitable solution.
Choosing the Right Blister Packing Machine Has Never Been Easier
Choose from different capsule blister packaging machine configurations to suit your business needs and witness your business grow exponentially.
DPP-88
- Application: Lab & Pilot Scale
- Max Depth: 26 mm
- Output: 4,800 p/h
- Changeover: < 20 Mins
DPP-160
- Application: Pharmacy/Clinic
- Max Depth: 26 mm
- Output: 4,200 p/h
- Control: PLC + HMI
DPP-260
- Application: Full Factory Line
- Max Depth: 26 mm
- Output: 10,800 p/h
- Feature: Servo Traction
Advanced Blister Packing Machine: AI Inspection & Balcony Design Solutions
| Key Differentiation | Advanced Technical Specifications | Strategic Operational Advantages |
|---|---|---|
| Machine Architecture | Balcony Type Design Innovative cantilever structure separating drive and operation zones for 100% GMP cleaning validation. | Easy Sanitation Prevents cross-contamination and simplifies line clearance—ideal for pharmaceutical-grade cleanrooms. |
| Quality Assurance | AI Vision Inspection Integrated deep-learning camera system for real-time detection of empty pockets, broken pills, or color defects. | Auto-Rejection High-speed defective blister rejection ensures 0% error rate in final carton packaging. |
| Changeover System | Tool-less Changeover Plug-and-play modular mold installation allows full format switch in under 15-30 minutes. | Minimum Downtime Rapid-positioning technology eliminates manual fine-tuning, maximizing OEE (Overall Equipment Effectiveness). |
| Data Compliance | CFR 21 Part 11 Advanced PLC control system with electronic signatures, audit trails, and multi-level user authentication. | Data Integrity Fully traceable production logs meeting stringent FDA and EU-GMP regulatory requirements. |
| Precision Sealing | Zero-Gap Cutting Servo-driven intermittent traction ensuring precise index and zero-waste material cutting between blisters. | Foil Saving Reduces PVC/Alu consumption by 10-15% annually through optimized matrix temperature control. |
Expert Blister Packaging Machine Manufacturer
20 Years of Precision Engineering & Automation Excellence
Since 2006, URMACHINE has been a leading force in the global pharmaceutical packaging industry. Operating from our10.,000m smart production base, we combine 20 years of manufacturing expertise with 50+ core patents to deliverbespokeautomation solutions. To date, we have deployed 600 high-performance units across 40 countries, earning the trustof 180+pharmaceutical giants woridwide. Our systems are engineered for total GMP and CE compliance, ensuring thehigheststandards of production efficiency and product integrity for our global partners.
Why Choose Urmachine Blister Packaging Solutions?
Precision Servo Indexing
Driven by high-performance dual-servo systems, our machines ensure sub-millimeter indexing accuracy, eliminating material drift and ensuring perfect registration for printed foils.
Universal Material Compatibility
Our modular stations seamlessly process PVC, ALU, PET, and Tropical foils, providing maximum flexibility for diverse pharmaceutical and nutraceutical packaging needs.
Hermetic Sealing Integrity
Utilizing advanced thermal regulation and high-pressure matrix sealing, we guarantee 100% leak-proof blisters to protect moisture-sensitive tablets and capsules.
Intelligent Waste Reduction
Equipped with "Zero-Gap" cutting technology, our equipment reduces raw material scrap by 10-15% annually, directly optimizing your production's total cost of ownership.
Tool-less Quick Changeover
The plug-and-play mold system allows for rapid size part replacement in under 20 minutes, significantly increasing OEE for facilities handling frequent format switches.
Global Regulatory Compliance
Fully compliant with cGMP and CE standards. Features 316L stainless steel contact parts and is 21 CFR Part 11 ready for full data integrity and traceability.
Comprehensive Support For Your Blister Packing Machine
How to Choose the Right Blister Packaging Technology: Flat Plate vs. Roller Type
Flat Plate Blister Packaging Machine
Forming Precision & Cold Forming Integrity
This technology utilizes intermittent motion combined with massive, uniform pressure. It is the industry benchmark for Alu-Alu (Cold Forming). By ensuring zero-stress material stretching, it eliminates the risk of pin-hole micro-cracks—a common failure in high-end barrier packaging.
Operational Excellence & OEE Drivers
High-speed throughput is the primary OEE (Overall Equipment Effectiveness) driver. It is engineered for 24/7 dedicated production lines where output per square meter of floor space is the critical KPI.
Advanced Quality Control Integration
Its horizontal, flat-bed layout provides the most stable platform for AI-driven Vision Inspection Systems. It allows for 100% dwell-time analysis of each pocket, ensuring that empty pockets, broken tablets.
Roller Type Blister Packaging Machine
Forming Precision & Cold Forming Integrity
Uses continuous roller motion and is primarily optimized for PVC/Alu (Thermoforming). While faster, it requires precise web tension control to prevent material curling, making it ideal for high-volume, standard-sized tablet runs.
Operational Excellence & OEE Drivers
Excels in Modular Versatility. With our SMED inspired Tool-less Changeover, it is the superior choice for Contract Manufacturing (CMO) or facilities handling multi-product small-batch runs.
Advanced Quality Control Integration
Due to the curvature of the sealing roller, integrating high-resolution pin-hole detection for Alu-Alu can be more technically demanding and may require specialized high-speed sensors.
